Materials:
Housing: PA9T, UL94V-0
Terminal: C7025, T=0.15mm,
3u" Gold Plating on contact points
1u" Gold Plated On Pin welding Area
Shell: SUS304, T=0.30mm
50u" Nickel Plating Over All
Salt Mist 48 Hour
Electric:
Rated Current: 5A
Contact Resistance: 40mΩ Max
Insulation Resistance: 100MΩ Min
Withstand voltage: 150V / 1mA Max
Insertion: 5~20N
Withdrawal Force: 8~20 N
Durability: 100000 Cycles,Withdrawal Force: 6 N Min
High temperafure resistance: SMT reflow soldering (peak value 260°±5℃), plastic should not have bubbles,
poor discoloration such as melting,and warping deformation within the tolerance range
Tin Adhesion Test: Tin adhesion area reaches 95% Min
Temperature Range: -30℃ ~ +85°C |
