2.54mm Pitch Single Row IDC Socket Connector KLS1-204P All Products in IDC connectors

2.54mm Pitch Single Row IDC Socket Connector


  Product Images
2.54mm Pitch Single Row IDC Socket Connector 2.54mm Pitch Single Row IDC Socket Connector


  Product Information

2.54mm Pitch Single Row IDC Socket Connector

Order Information:
KLS1-204P-XX-B
XX-No.of 8~24pin
B-Black

Material:
Housing: 30% Glass filled PBT UL94V-0
Contacts: Phosphor Bronze
Plating:Au or Sn over 50u" nickel
Electrical Characteristics:
Current Rating: 1.0 AMP
Insulator Resistance: 1000M Ohm min.
Withstand Voltage: 500V AC / Minute
Contact Resistance: 20m Ohm max.
Operating Temperature: -40ºC~+105ºC

Part No.Description PCS/CTN G.W.(KG) CMB(m3) Order Qty. Time Order
KLS1-204P-08-B2.54mm Pitch Single Row IDC Socket Connector,8 Pins,Black.
KLS1-204P-10-B2.54mm Pitch Single Row IDC Socket Connector,10 Pins,Black.
KLS1-204P-14-B2.54mm Pitch Single Row IDC Socket Connector,14 Pins,Black.
KLS1-204P-16-B2.54mm Pitch Single Row IDC Socket Connector,16 Pins,Black.
KLS1-204P-24-B2.54mm Pitch Single Row IDC Socket Connector,24 Pins,Black.
